Bathology Spectrum 441D
Sauna Room / Dimmable LED Lighting System, Single Zone
Distinctive and stylish, these flush-fitting, water-proof LED light fixtures will illuminate your sauna environment while emphasizing the depth and beauty of the wood surfaces. One system can power from 1 to 10 lights. One waterproof LED light fixture w/ frosted lens included.
Distinctive and stylish, these flush-fitting, water-proof LED light fixtures will illuminate your sauna environment while emphasizing the depth and beauty of the wood surfaces. One system can power from 1 to 11 lights, allowing you to custom tailor the ambience of your room and ensure a safe and inviting bathing space.
The flush-mounted lights may be directed to highlight and define specific areas and enhance the safety or visual effect. Their compact 1-1/4” diameter lens and integrated appearance make them perfect for ceilings, bench skirting and steps, and to illuminate walkways. An IP68 immersion rating ensures you that these lights are engineered and trusted as safe for use in wet areas.
Beauty and Durability
Spectrum 441 lights are impervious to corrosion and employ a polished sealed stainless steel bezel mounted to a robust aluminum body. With rugged construction and 100,000-hour LED’s, these lights will provide a lifetime of bathing splendor.
Easy Installation
The Spectrum 441’s transformer mounts easily and can be connected to a switchable 120VAC power source. Power is converted to a low-voltage12V, and is routed in series to each light fixture using cable in lengths available from 25 to 100 feet. A single transformer may be used to connect up to eleven lights.
Meticulous planning and consideration has been taken to ensure easy and trouble-free and water-tight installation making the Spectrum 441 a must for new construction or rebuild projects. Tradesman and installers will appreciate the installation template supplied with each system for precise light placement every time. The compact size also provides a greater variety of placement options.
- Suitable as primary light source
- 11-Light capacity
- Polished stainless steel bezel
- Tempered frosted glass lens
- Water-safe materials
- Aluminum Material
- Luminous Flux 142±2.5%
- Pure-white LED light
- 120 Degree beam angle
- Dimmable
- Safe operation
- Ease of installation
- Flush-mounted, low-profile design
- IP68 immersible rating
- One waterproof LED light fixture w/ frosted lens
- Mounting template
- Male NEMA Cable
- Light cable
- Wire fit cap
- Silicone Sealant 1oz
Model | Spectrum 441D |
---|
Brilliance Fixture | |
---|---|
Type | LED White (3500K) |
Operating Voltage | 12V DC |
Maximum Input Current | 700mA |
LED | 1 x 3 Watt |
Beam Angle | 35 degree |
Lumens | 142 Lumens max per fixture |
Trim Finish | Polished Stainless Steel |
Housing Composition | First Grade Aluminum |
Lens | Frosted, 1-7/32” Diameter |
Lens Composition | Tempered Glass |
Rough-in Cutout | 1-5/8” to 1-11/16" |
Trim Dimension | 2-3/64” Diameter, 1/8” Profile |
Body Dimensions | 1-15/32” Diameter x 1-7/8” Deep |
Rating | IP68 |
Certifications | CE / RoHS / WEEE |
Dimmable | YES |
Driver | |
---|---|
Operating Voltage | 90-305 VAC |
Dimensions | 4-1/8" W x 2-1/2" H x 1-3/16" D |
Dimmer | |
Type | 0-10V |
Enclosure | |
---|---|
Housing Composition | Steel, black powder coated finish |
Dimensions | 7-3/4”W x 1-7/8”H x 4-7/8”D |
Standards | NEMA 1 |
Listing | ETL,UL |
